1 ENGINE SYSTEMS 35
Fuel Flow
2
18
H11049
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
19 20
2221
23
Figure 30 Fuel
filter assembl y
1. Housing cove
r assembly
2. M12 port fittin
g(factoryfill)
3. O-ring seal
4. Fuel filter elem
ent
5. O-ring seal
6. Fuel pressure r
egulator
assembly
7. Plug or EFP sens
or (optional)
8. Fuel filter ho
using
9. Plug assembly
,M10
10. Fuel strainer
11. Bowl O-ring sea
l
12. Fuel bowl (with h
eater option)
13. Drain valve
14. Fitting assembl
y, ⅜ tube
15. Water dra in valv
e assembly
16. Self tapping
screw (4)
17. Cartridge che
ck valve
18. Retainer ring
19. Primer pump ass
embly
20. Bolt, M8 x 20 (2)
21. Primer pump s ea
l
22. Water In Fuel (WI
F) sensor
23. Stand pipe
EGES-270-1
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© August 2008 Navistar, Inc.
