7 ELECTRONIC CONTROL SYSTEMS DIAGNOSTICS 517
The RSE circuit requires the use of vehicle circuit diagrams. See truck Chassis E lec
trical Circuit D ia gram
Manual for circuit numbers, connector and fuse locations.
Voltage Checks at Solenoid Connector (Disconnect s olenoid. Turn the ignition switch to ON.)
Test Point
Spec Comment
KOEO
Atognd B+±0.5V
If < B+, check for open circuit. Do Harness Resistance
Checks.
B to gnd 0 V to 0.25 V
If > 0.25 V, check ECM programming or open circuit.
Output State Test - Voltage Check at Shutter Connector (D
isconnect solenoid. Turn the ignition switch to
ON. Run the Output State Tests. For help, see “Diagnosti
c Software Operation” in Section 3 (page 68) for
procedure to run the Low and High Output State Tests.)
Test State/Po in t Spec Comment
Output State Test - Low
B+ to Pin B B+ ± 0.5 V
If < B+, check ECM programming and check for ope
n circuit.
Output State Test - High
B+ to Pin B 0 V to 0.25 V
If > 0.25 V, check ECM programming and check for short
to voltage source.
RSE Solenoid Continuity Check (Turn th
e ignition switch to O F F. Disconnect solenoid.)
Btognd
>1kΩ If < 1 kΩ, check for short to ground.
Atognd
>1kΩ If < 1 kΩ, check for short to ground.
BtoA
10 Ω to 30 Ω Expected coil resistance for solen
oid.
WARNING: To avoid serious person
al injury, possible death, or damage to the engine or vehicle,
always disconnect main negativ
ebatterycablefirst. Always connect the main negative battery cable
last.
Connector Resistance Checks to
Chassis Ground (Turn the ignition switch to OFF. Disconnect negative
battery cable. Disconnect sol
enoid. Use disconnected negative battery cable for ground test point.)
A to gnd cable
>1kΩ If < 1 kΩ, check for short to ground.
B to gnd cable
>1kΩ If < 1 kΩ, check for short to ground.
Harness Resistance Checks
(Turn the ignition switch to OFF. Disconnect solenoid. Connect breakout
box X3 to chassis wiring ha
rness only. )
X3–22 to B
<5Ω If > 5 Ω, check for harness open between ECM and fan
solenoid.
AtoFuse
<5Ω If > 5 Ω, check for harness open between fuse and fan
solenoid. See truck Chassis Electrical Circuit Diagram
Manual for fuse information.
EGES-270-1
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
