Virtual Private Networking Using IPSec and L2TP Connections
270
NETGEAR ProSAFE VPN Firewall FVS318G v2
d. Click anywhere in the tree list pane.
This is the name for the authentication phase that is used only for the VPN client, no
t
during IKE negotiation. You can view and change this name in the tree list pane. This
name must be a unique name.
4. Specify the settings that are described in the following table.
5.
To use the new settings immediately, click the Apply
button.
6. To keep the settings for future use, click the Save
button.
Table 58. VPN client authentication settings (Mode Config)
Setting Description
Interface Select Any from the list.
Remote Gateway Enter the remote IP address or DNS name of the VPN firewall. For example, enter
192.168.15.175.
Preshared Key Select the Preshared Key radio button. Enter the pre-shared key that you already
specified on the VPN firewall. For example, enter H8!spsf3#JYK2!. Confirm the key
in the Confirm field.
IKE Encryption Select the 3DES encryption algorithm from the list.
Authentication Select the SHA1 authentication algorithm from the list.
Key Group Select the DH2 (1024) key group from the list.
Note: On the VPN firewall, this key group is referred to as
Diffie-Hellman Group 2 (1024 bit).
