14.16.3 Antenna Control Interface Alarm Table
The alarm table provides a clear overview of the current antenna status.
Parameter Description
Index
Indicates the Control ID of the antenna connection that is being monitored.
Controller
Communication
Green: The IP communication between the antenna control interface and the
antenna control unit is active.
Red: The IP communication between the antenna control interface and the
antenna control unit is inactive.
• Check the configured destination IP address (IP address of the antenna
control unit.).
• Check cabling between the MDM9000 and the antenna unit.
Antenna
Functional
Status
Green: The antenna control unit is active.
Red: The antenna control unit is inactive.
• Check the configuration.
• Check if equipment failure is causing the alarm,
for example:
– Is the antenna control unit powered up?
