Feature Descriptions
MDM9000 Satellite Modem
16.1.2 Transmit
MDM9000 >> Modulator >> Transmit
This is the modulator output transmission.
Enable transmit when the complete configuration is done according to the system requirements.
A warning is displayed when it is not allowed to change a parameter when transmit is
enabled.
This will be the case with parameters that influence the transmitted signal and its
spectrum.
Please refer to section TransmitControlonpage169 to overrule this default behavior.
Transmit State Reason
The parameter displays why the transmission is on or off. This parameter is valuable when the
transmission is off due to an alarm. It reflects the alarm state's that are configured under transmit
control.
16.1.3 Output Frequency and Output Band
MDM9000 >> Modulator >> Output Frequency
Set the output frequency of the modulator. The output frequency must be in-line with the system
requirements.
Output Frequency
• L-band: 950 MHz to 2150 MHz
• IF-band: 50 MHz to 180 MHz
The device performs a check whether the inserted frequency is within the allowed frequency range.
