Feature Descriptions
MDM9000 Satellite Modem
16.10.3 Set the DC BUC Power for L-Band TX
MDM9000 > Modulator >> BUC Power on L Band TX
Parameter Value Description
Enable On/Off
Enable or Disable the L-Band DC supply.
voltage
24 V /
48 V
Select the appropriate voltage for the equipment used in
combination with the DC supply.On the back panel the
corresponding LED is activated.
Note: It is not possible to change this value when
the DC supply is enabled.
Measured
Output
Voltage
Range
0V/48V
Displays the actual voltage level on the L-band Tx interface.
Output
Current
Range
0A/8A
Displays the actual current being delivered by the DC supply:
• When an overcurrent is detected the circuit protection
mechanism is triggered and disables the DC supply.
The protection mechanism monitors every 1 s if the overload
(overcurrent) is removed. The overload alarm is active.
• When a short circuit is detected the circuit protection mechanism
is triggered and disables the DC supply.
The protection mechanism monitors every 5 s if the short circuit
is removed.
The short circuit alarm is active.
