Newtec MDM9000 - QOS Rule to Drop Incoming Traffic

Newtec Proprietary
Confidentiality: Unrestricted
R3.2_v1.0
256/387
Feature Descriptions
MDM9000 Satellite Modem
16.11.4 QOS Rule to Drop Incoming Traffic
When unwanted IP traffic is arriving on the device, malicious or just traffic you don't want to transmit
over the air, the MDM9000 makes it possible to classify this traffic and drop it.
Refer to the following figure:
Proceed as follows to discard this traffic:
» Add a classification rule (to select the unwanted traffic).
» Select the discard node.
All traffic that is captured by the rule is discarded (dropped), no further processing is performed on
this traffic.
MDM9000 >> Encapsulation >Shaping
