How to Manage the Device
MDM9000 Satellite Modem
13.2 Management Ethernet Interfaces
Management interface 1 (Mgmt1) is activated by default; the other interfaces can be enabled on the
following location in the device.
MDM9000 >> Device Setup >> Mgmt Interface
• Mgmt1 (This the top port on the back panel indicated as Mgmt1)
• Mgmt2 (This the bottom port on the back panel indicated as Mgmt2)
• Mgmt Frontpanel (This is the Ethernet port that is found on the front panel)
Do not disable the active management interface (interfaces) because this makes the
device unreachable.
(The interface can be enabled again using the front panel buttons).
When link redundancy is used, Mgmt1 and Mgmt2 must be enabled and auto
negotiation must be on. To enable link redundancy, refer to
EthernetLinkRedundancyonpage53 .
Statistics
MDM9000 >> Device Setup >> Mgmt Interface >> Statistics
This provides an overview of the amount of traffic that is passing over the different management
Ethernet ports.
The following statistics are displayed:
• Input Bytes
• Input Packets
• Input Dropped
• Input Errors
• Output Bytes
• Output Packets
• Output Dropped
• Output Errors
