Feature Descriptions
MDM9000 Satellite Modem
16.12 Stream Decapsulation
Baseband frames coming from the satellite (processed by the MDM9000 Satellite Modem) are
inserted in one of the two input satellite interfaces. The BBFs are decapsulated by stripping of the
protocol header information, GSE, XPE, MPE or ULE.
The payload data is available on one of the two output interfaces Data1/Data2.
The decapsulator can handle Layer 3 and Layer 2 traffic, as described in
EncapsulationGeneralSettingsonpage230.
MDM9000 Satellite Modem >> Decapsulation
16.12.1 Decapsulation General Settings
Enable this functional block to perform decapsulation on the incoming IP data (coming from the
satellite).
