Appendix - Technical Specifications
MDM9000 Satellite Modem
22.8.1.4 DVB-S2 Performance (FER<1E-5) Short Frames/Pilots On
MODCOD
Thresh Es/No
10 Mbaud
dB
Thresh Es/No
36 Mbaud
dB
Thresh Es/No
72 Mbaud
dB
QPSK 1/4
-3.36 -3.42 -3.39
QPSK 1/3
-1.19 -1.24 -1.21
QPSK 2/5
-0.24 -0.26 -0.24
QPSK 1/2
0.56 0.52 0.52
QPSK 3/5
2.38 2.34 2.36
QPSK 2/3
3.24 3.20 3.21
QPSK 3/4
4.17 4.15 4.15
QPSK 4/5
4.77 4.75 4.75
QPSK 5/6
5.33 5.30 5.30
QPSK 8/9
6.40 6.37 6.37
8PSK 3/5
5.71 5.71 5.76
8PSK 2/3
6.77 6.74 6.77
8PSK 3/4
8.09 8.07 8.08
8PSK 5/6
9.57 9.57 9.57
8PSK 8/9
10.89 10.89 10.91
16APSK 2/3
9.16 9.15 9.21
16APSK 3/4
10.43 10.43 10.44
16APSK 4/5
11.17 11.20 11.20
16APSK 5/6
11.85 11.88 11.89
16APSK 8/9
13.13 13.18 13.18
32APSK 3/4
13.11 13.17 13.19
32APSK 4/5
13.94 14.04 14.05
32APSK 5/6
14.58 14.77 14.77
32APSK 8/9
15.93 16.15 16.14
