Feature Descriptions
MDM9000 Satellite Modem
16.1.7 Clock Output
MDM9000 >> Modulator >> Clock Output
Enables or disables the transmission of a 10 MHz clock signal on the L-Band output interface.
For the reference clock settings and characteristics, refer to ReferenceClockonpage138.
16.1.8 Carrier Modulation
MDM9000 >> Modulator >> Carrier Modulation
This command controls the carrier modulation:
• On (Operational modulated carrier signal)
• Pure Carrier (unmodulated output signal)
• Test modulation (pulse)
• Test modulation (clock/4)
• Test modulation (clock/8)
• Test modulation (clock/16)
