General Device Settings and Actions
MDM9000 Satellite Modem
14.9 Device Monitoring
MDM9000 >> Device Setup >>Monitor
The following device level parameters are monitored.
• Temperature
• Board Power supply
• CPU (Central Processor Unit) load
• Memory usage
• Uptime
14.10 Device Redundancy
Redundancy is very important as a single failure of the MDM9000 affects many services at the same
time.
Reliable operation of the MDM9000 in a satellite network is of key importance. The MDM9000 works
seamlessly together with the Newtec USS0202/USS0212 redundancy switches to provide
best-in-class system uptime.
Refer to the user manual of the USS0202/USS0212 Universal Switching System.
The following figures shows a 1+1 protection scheme built up with the USS0202 switch, one in
normal operation and one in redundant operation.
Normal Operation
