Newtec MDM9000 - DVB-S2 Performance (FER<1 E-5) Normal Frames;Pilots Off

Newtec Proprietary
Confidentiality: Unrestricted
R3.2_v1.0
357/387
Appendix - Technical Specifications
MDM9000 Satellite Modem
22.8 Demodulation Performances
22.8.1 DVB-S2 Performance
22.8.1.1 DVB-S2 Performance (FER<1E-5) Normal Frames/Pilots Off
MODCOD Thresh Es/No
10 Mbaud dB
Thresh Es/No
36 Mbaud dB
Thresh Es/No
72 Mbaud dB
QPSK 1/4 -2.79 -2.85 -2.86
QPSK 1/3 -1.51 -1.55 -1.56
QPSK 2/5 -0.47 -0.50 -0.50
QPSK 1/2 0.93 0.90 0.91
QPSK 3/5 2.19 2.15 2.15
QPSK 2/3 3.04 3.00 3.00
QPSK 3/4 4.02 3.98 3.98
QPSK 4/5 4.65 4.62 4.62
QPSK 5/6 5.17 5.13 5.13
QPSK 8/9 6.22 6.18 6.17
QPSK 9/10 6.43 6.40 6.39
8PSK 3/5 5.54 5.52 5.54
8PSK 2/3 6.54 6.48 6.49
8PSK 3/4 7.86 7.81 7.82
8PSK 5/6 9.29 9.27 9.28
8PSK 8/9 10.69 10.67 10.68
8PSK9/10 10.97 10.94 10.95
16APSK 2/3 9.00 8.97 8.99
16APSK 3/4 10.21 10.19 10.22
16APSK 4/5 11.03 11.02 11.02
16APSK 5/6 11.61 11.59 11.60
16APSK 8/9 12.93 12.92 12.92
16APSK 9/10 13.17 13.14 13.17
32APSK 3/4 12.75 12.74 12.78
32APSK 4/5 13.69 13.70 13.68
32APSK 5/6 14.26 14.30 14.27
32APSK 8/9 15.71 15.71 15.73
32APSK 9/10 16.02 16.00 16.17
