Physical Description
MDM9000 Satellite Modem
9.2.3 Craft Interface
The craft interface is a SUBD 9 pin connector interface that can be used to manage the device using
the command line interface (CLI). For more information please refer to section:
CommandLineInterface(CLI)onpage82
It is used to control the device over RS232.
The line settings for the craft interface are:
• Speed 115200 baud
• Eight data bits
• No parity bit
• One stop bit
Use the following pin connections to create a crossover cable between the MDM9000
Satellite Modem and the managing device.
Pin Name Function
1
Not connected
2 RX-D
Receive Data
3 TX-D
Transmit Data
4
Not connected
5 GND
Shield ground
6
Not connected
7
Not connected
8
Not connected
9
Not connected
The following figure shows the craft interface connection.
