Block Diagram
MDM9000 Satellite Modem
10.8 Decapsulation
The decapsulator, decapsulates the incoming BBFs. It strips of the BBF header and retrieves the
original IP traffic. According to the settings in the decapsulator the IP traffic is forwarded towards the
next equipment in the system setup.
To have the communication set up correctly the decapsulator must filter on the correct ISI.
Next to the ISI the incoming channel name(s) must be defined correctly along with its label and label
filter if they are used.
For more information please refer to section: StreamDecapsulationonpage258.
