Block Diagram
MDM9000 Satellite Modem
10.1 Device Management
This functional block contains all the configuration parameters concerning the management
interfaces.
In this block, it is also possible to configure or look up the following:
• Ethernet connectivity
• IP connectivity
• Interface Link Redundancy
• Device Redundancy
• Identification of the device
• Consult all the device options that are activated on the device including the sales code
10.2 Data Input and Output Interfaces
These Ethernet connectors are bidirectional and are used as input and output interfaces,
transporting IP traffic.
Configure the Ethernet and IP connectivity, including the data gateway IP address of the data
interfaces. Also configure the data interface link redundancy (bonding) in this block.
