Data Interfaces
MDM9000 Satellite Modem
15 Data Interfaces
15.1 Data Ethernet Interfaces
The data interfaces can be configured on the following location:
MDM9000 >> Data Interface >> Ethernet
• Data1 (This port is the top port on the back panel indicated as Data1).
• Data2 (This port is the bottom port on the back panel indicated as Data2).
When link redundancy is needed, Data1 and Data2 must be enabled and auto
negation must be on. To enable link redundancy, refer to section:
DataEthernetLinkRedundancyonpage150.
Per interface, the following information is displayed.
• Default interface name; (read only)
• Enabled (On/Off)
• MAC address
• Auto Negotiation (On/Off)
• Advertised Speeds
• Forced Speed
• Link State
• MTU (Maximum Transmission Unit)
Range: 68 - 9582
Statistics
MDM9000 >> Data Interface >> Statistics
This provides an overview of the traffic that is passing over the different Ethernet ports.
The following statistics are displayed:
• Input Bytes
• Input Packets
• Input Dropped
• Input Errors
• Output Bytes
• Output Packets
• Output Dropped
• Output Errors
