How to Manage the Device
MDM9000 Satellite Modem
13.5 Graphical User Interface
The graphical user interface is a web application that gives remote access to the MDM9000. It allows
the user to:
• Manage the device
• Create or change configurations
• Monitor the status of the MDM9000 through alarms
The GUI is optimized for displays with a screen resolution of 1024 x 768 or higher.
13.5.1 Opening the GUI
Proceed as follows to open the GUI on a computer in the network:
» Open a web browser.
Use one of the most commonly used browsers to open the GUI.
» Type the IP address of the device in the address bar of the browser. The default IP address is
10.0.0.1/24.
Make sure that the management PC has access to this IP Address or it belongs to this
IP range. If needed it is possible to configure the Mgmt Gateway.
» Press Enter.
The following graphical user interface is displayed.
