Feature Descriptions
MDM9000 Satellite Modem
16.8.5.1 Gather all Block Up Converter Specifications
The BUC specifications should be consulted by the responsible installer to ensure:
• That the BUC is operated with sufficient power backoff to keep the spectral re growth below
required limits.
• That the BUC back-off is sufficient under all temperature conditions.
Acquiring the specifications of the BUC is the full responsibility of the operator!
Also verify the link budget for the uplink noise limited link.
16.8.5.2 Configuration of the AUPC Controller
The following figure shows the AUPC controller and the clear weather conditions that should be
respected during configuration of the AUPC feature.
The following table describes the different AUPC controller parameters.
MDM9000 >> AUPC Controller
