Block Diagram
MDM9000 Satellite Modem
10 Block Diagram
The following figure shows the block diagram of the MDM9000 Satellite Modem. The block diagram
represents the main functional blocks in the device and the data flow through the device.
Depending on the hardware and software configuration of the device, some functional blocks can be
available or not.
The block diagram is derived from the synoptic view of the Graphical User Interface.
