Feature Descriptions
MDM9000 Satellite Modem
16.6.3 Input Frequency
MDM9000 >> Demodulator >> Input Frequency
Set the input frequency of the demodulator.
Output Frequency
• L-band: 950 MHz to 2150 MHz
• IF-band: 50 MHz to 180 MHz
The device performs a check whether the entered frequency is within the allowed frequency range.
16.6.4 Symbol Rate
Define the symbol rate in Mbaud.
16.6.5 Acquisition Range
Define the amount of frequency uncertainty the demodulator will search over in order to find and
lock to an incoming carrier.
The range is between 0.05 MHz to 7.5 MHz.
16.6.6 Roll-Off Factor and Occupied Bandwidth
MDM9000 >> Modulator >> Roll-Off
Select the appropriate roll-off factor.
The possibilities are:
• 35%
• 25%
• 20%
• 15% (Clean Channel Technology)
• 10% (Clean Channel Technology)
• 5% (Clean Channel Technology)
