16.1.9 Amplitude Slope Equalizer
MDM9000 >> Modulator >> Ampl Slope Equalizer
Configure the amplitude slope equalizer. An amplitude slope in the up-converter or in the high
power amplifier can be compensated by using this equalizer. The equalizer has a maximum range of
± 2 dB/50 MHz.The compensation can be set in the range between -7 and +7.
The slope equalizer can also be used to compensate for cable slope.
16.1.10 Symbol Rate
MDM9000 >> Modulator >> Symbol Rate
Define the symbol rate in Mbaud.
16.1.11 Stream Mode
MDM9000 >> Modulator >> Stream Mode
Select the appropriate stream mode:
• Single-stream
• Multistream
16.1.12 Measured Packet Count and Measured Bit Rate
The measured packet count should be incrementing.
The measured Bit Rate should match the bit rate inserted by the source device.
