How to Manage the Device
MDM9000 Satellite Modem
13.6.7 Example: Set the Input Frequency
» Select Demodulator using the corresponding Soft button.
» Navigate to Input Frequency.
» Click OK.
New value is displayed, indicating the current position by a blinking number.
» Insert the new value using the corresponding Soft Buttons.
» Click OK.
» The new value is displayed on the front panel.
13.6.8 Example: Set the Output Frequency
» Select Modulator using the corresponding Soft Button.
» Navigate to Output Frequency.
» Click OK.
New value is displayed, indicating the current position by a blinking number.
» Insert the new value using the corresponding Soft Buttons.
» Click OK.
» The new value is displayed on the front panel.
13.6.9 Example: Check the Alarms
» Select Alarms using the corresponding Soft Button.
(Use the soft button arrows to navigate through the root menu.)
» Navigate to Active Alarms or Memorized Alarms.
» Click OK.
» Navigate through the tree menu to see the active or memorized alarms.
It is possible to clear the Memorized Alarms by pressing the OK button during three
seconds.
