Feature Descriptions
MDM9000 Satellite Modem
The Automated Equalink 3 calibration procedure is designed to automatically take into account all
these factors to configure Equalink 3 in the best possible way with minimal user interaction.
A detailed document describing the automated Equalink 3 calibration procedure can
be delivered upon request.
Please use the Newtec Service Desk tool to receive more information.
> Browse to https://customersupport.newtec.eu.
> Fill in your Username and Password
> Create a ticket
In response to your request you will receive the document from our support team.
In case you don't have a Username and Password yet for the Newtec Service Desk
tool: request a login to customersupport@newtec.eu.
In order to do a complete Equalink 3 calibration, the following procedures are typically performed in
the presented order:
• Satellite Link Analysis (to verify the present conditions, such as the TWTA drive level, and uplink
and downlink noise level).
• Automated Linear Equalink 3 Calibration (run and enable afterwards).
• Automated Non-Linear Equalink 3 Calibration (run and enable afterwards).
• Satellite Link Analysis
(to verify the link optimality and to give an overview of the gain of Equalink 3).
For broadcast or distribution links that are using a single carrier per transponder, both linear and
Non-Linear pre-distortion can give much link margin gain.
