Feature Descriptions
MDM9000 Satellite Modem
The following table describes the calibration table, use it to define the nominal input level and the
nominal Es/No value:
Parameter Value Description
Calibration
Index 1
This is the ID of your demodulator.
Nominal Input
Level
dBm The nominal input level should be the same as the input
level measured by the monitoring tool of the satellite
operator during calibration.
During the calibration
Copy the measured input level and "paste" it as the
nominal input value.
During operation
The nominal input level is used as a reference. The
moment fading is present in the uplink a variation will
be detected and a compensation will monitored.
Nominal Es/No dB The nominal Es/No value should be the same as the
Es/No measured by the monitoring tool of the satellite
operator during calibration.
During the calibration
Copy the measured Es/No level and "paste" it as the
nominal input value.
The nominal Es/No value is used as a reference. The
moment fading is present in the uplink, a compensation
will be monitored in accordance to this reference.
