Feature Descriptions
MDM9000 Satellite Modem
Parameter Description
Channel Name Enter a logical channel name, for example the service that is transported
over this channel (ACM Signalling, VoIP Traffic).
Enable
This must be Enabled (On) otherwise the channel is not recognized and the
data cannot be encapsulated.
ISI
Insert the Input Stream Identifier to link the channel with an encapsulator.
Label
Enter a Label that you want to assign to this channel.
For more information refer to GSEHeaderonpage348.
In a unicast configuration, the channel corresponds with one terminal.
In a "multicast" configuration, a "multicast Label Type" must be specified and
the terminals belonging to the specified "multicast label type group" can
receive the channels.
A receiver has the "multicast Label Type" configured in its filters, in the case
of a hardware receiver and in the decapsulation configuration block in the
case of a software receiver (NOP1760).
Nominal
MODCOD
Define the initial MODCOD (in case of ACM) or the actual MODCOD (incase
of no ACM) used in the system setup.
Depending on the modulation standard, define it for DVB-S2, DVB-S2X or
S2 Extensions.
The available MODCODs are dynamically changed according to the link
optimization setting.
ACM Enable Use this to activate or deactivate FlexACM® signaling.
Terminal
Name
When ACM is active, then the terminal name must correspond with the
terminal name of the receiving device. This to make sure that the ACM
signaling is transported to the correct device.
The terminal name of the receiving device is defined under
Root >> Terminals
