Feature Descriptions
MDM9000 Satellite Modem
Parameter Description
The following figure is an example of a converted L-band frequency.
Bandwidth Mode This parameter sets the range of parameters of the acquisition loops.
Use the bandwidth mode to balance the search range versus the
acquisition time.
• Normal: Standard settings for the acquisition loops.
• Robust: Extended ranges of the parameters in the acquisition loops.
Use the this setting to cope with bigger uncertainties but potentially
increases lock time.
• Fine: When all parameters are accurately known and set and there is
no change over time, use the fine mode to achieve the fastest lock
time.
