Appendix - Technical Specifications
MDM9000 Satellite Modem
• DVB-S2X (Optional)
Outer/Inner FEC: BCH/LDPC
53 MODCODs (normal frames):
QPSK
from 1/4 to 9/10
8PSK
from 3/5 to 9/10
16APSK
from 26/45 to 9/10
32APSK
from 32/45 to 9/10
64APSK
from 11/15 to 5/6
128APSK
3/4; 7/9
256APSK
32/45; 3/4
13 Linear MODCODs (normal frames):
8PSK-L
5/9; 26/45
16APSK-L
from 1/2 to 2/3
32APSK-L 2/3
64APSK-L 32/45
256APSK-L
from 29/45 to 11/15
41 MODCODs (short frames):
QPSK
from 11/45 to 8/9
8PSK
from 1/2 to 2/3
16APSK
from 7/15 to 8/9
32APSK
from 2/3 to 8/9
