Newtec Proprietary
Confidentiality: Unrestricted
R3.2_v1.0
352/387
Appendix - Technical Specifications
MDM9000 Satellite Modem
BAUD RATE RANGE
Modulator
0,050 - 72 Mbaud
Class 1 Demodulator
(depending on MODCOD)
1 - 60 Mbaud
Class 2 Demodulator 256 kbaud - 72 Mbaud
FRAME LENGTH
DVB-S2 Short Frames 16200 bits for DVB-S2, and
DVB-S2X
DVB-S2 Normal Frames 64800 bits for DVB-S2, DVB-S2X
and Newtec's S2 Extensions
CLEAN CHANNEL TECHNOLOGY
Roll-off : 5% -10% -15% -20% - 25% - 35%
Optimum carrier spacing
Advanced filter technology
AUTOMATED EQUALINK (TM) 3
Non-linear pre-distortion for all MODCODs
CARRIER INTERFERENCE REDUCTION
DVB RF Carrier ID (DVB-CID)
Spread Spectrum Modulator (BPSK)
Supports User Data
Compliant to DVB Standard
