Appendix - Technical Specifications

MDM9000 Satellite Modem

10 MHZ REFERENCE OUTPUT (OPTIONAL)

Connector

BNC (F), 50 ohms

Input level +3 dBm (+/- 2 dB)

BUC POWER (OPTIONAL)

Max. current 3.8 A

Voltage

24V, 48 V (Software controlled)
