Appendix - Technical Specifications
MDM9000 Satellite Modem
MODCOD
Thresh Es/No
10 Mbaud
dB
Thresh Es/No
36 Mbaud
dB
Thresh Es/No
72 Mbaud
dB
8APSK 5/9-L
4.69 4.65 4.66
8APSK 26/45-L
5.12 5.08 5.08
16APSK 1/2-L
5.90 5.85 5.89
16APSK 8/15-L
6.54 6.50 6.52
16APSK 5/9-L
6.80 6.77 6.79
16APSK 3/5-L
7.32 7.28 7.34
16APSK 2/3-L
8.36 8.32 8.36
32APSK 2/3-L
11.21 11.11 11.14
64APSK 32/45-L
14.02 13.97 14.02
256APSK 29/45-L
17.02 16.97 17.16
256APSK 2/3-L
17.36 17.28 17.46
256APSK 31/45-L
18.31 18.21 18.30
256APSK 11/15-L
19.06 18.96 19.09
