Appendix - Technical Specifications
MDM9000 Satellite Modem
MODCOD
Thresh Es/No
10 Mbaud
dB
Thresh Es/No
36 Mbaud
dB
Thresh Es/No
72 Mbaud
dB
QPSK 13/45
-1.98 -2.03 -2.04
QPSK 9/20
0.23 0.20 0.20
QPSK 11/20
1.47 1.45 1.45
8PSK 23/36
6.21 6.18 6.19
8PSK 25/36
7.11 7.07 7.08
8PSK 13/18
7.58 7.54 7.55
16APSK 26/45
7.44 7.40 7.44
16APSK 3/5
7.89 7.85 7.87
16APSK 28/45
8.17 8.13 8.14
16APSK 23/36
8.39 8.34 8.37
16APSK 25/36
9.30 9.26 9.28
16APSK 13/18
9.81 9.76 9.77
16APSK 7/9
10.75 10.70 10.71
16APSK 77/90
12.11 12.05 12.06
32APSK 32/45
11.86 11.81 11.85
32APSK 11/15
12.27 12.22 12.25
32APSK 7/9
13.19 13.13 13.15
64APSK 11/15
14.97 14.91 14.96
64APSK 7/9
15.61 15.54 15.58
64APSK 4/5
16.07 15.97 16.00
64APSK 5/6
16.68 16.61 16.65
128APSK 3/4
17.96 17.90 17.97
128APSK 7/9
18.87 18.78 18.82
256APSK 32/45
18.95 18.84 18.92
256APSK 3/4
19.92 19.81 19.91
