Appendix - Technical Specifications
MDM9000 Satellite Modem
MODCOD
Thresh Es/No
10 Mbaud
dB
Thresh Es/No
36 Mbaud
dB
Thresh Es/No
72 Mbaud
dB
QPSK 11/45
-2.50 -2.54 -2.55
QPSK 4/15
-2.13 -2.16 -2.16
QPSK 14/45
-1.47 -1.50 -1.49
QPSK 7/15
0.64 0.60 0.64
QPSK 8/15
1.51 1.48 1.48
QPSK 32/45
3.65 3.62 3.62
8PSK 7/15
3.74 3.75 3.84
8PSK 8/15 -
4.66 4.65 4.67
8PSK 26/45
5.42 5.39 5.41
8PSK 32/45
7.59 7.55 7.56
16APSK 7/15
5.94 5.94 6.14
16APSK 8/15
6.90 6.89 6.95
16APSK 26/45
7.60 7.58 7.63
16APSK 3/5
8.07 8.06 8.12
16APSK 32/45
9.81 9.76 9.78
32APSK 2/3
11.38 11.36 11.44
32APSK 32/45
12.18 12.11 12.15
