Newtec MDM9000 - Page 392

Newtec Proprietary
Confidentiality: Unrestricted
R3.2_v1.0
380/387
Appendix - Back Panel Combinations
MDM9000 Satellite Modem
Ordering Options
Figure
PS-00
PS-01
Note: The dual PSU option PS-01 cannot be combined with OU-05 nor
OU-06!
PS-10
Note: The option PS-10 cannot be combined with OU-05 nor OU-06!
PS-11
Note: The option PS-11 cannot be combined with OU-05 nor OU-06!
