You can identify the datalogger parameters in the ID bar at the top of the
measurement screen (see Figure 6-16 on page 90).
Figure 6-16 Identifying datalogger parameters
With each measurement, the 45MG also stores a complete description of the
measurement conditions. Table 6 on page 91 describes the additional data stored with
each thickness measurement and with each waveform.
Measurement
data
Organized by predefined IDs arranged by file
types
“Data File
Types” on
page 93
Data format defined by the file data mode “File Data
Modes” on
page 104
Saved data (thickness measurement with or
without the waveform) configured using the
setup menu
“Saving
Data” on
page 65
Table 5 File contents summary (continued)
Contents Description See section
ID number
Previous thickness
ID bar
