DMTA-10022-01EN, Rev. C, January 2015
Instrument Description 21
The USB and Transmit/Receive transducer connectors are located on the top of the
45MG (see Figure 1-3 on page 21).
Figure 1-3 The top end connectors
The external microSD memory card slot is located behind the battery door (see
Figure 1-4 on page 21).
Figure 1-4 The microSD connector behind the battery door
USB communication
connector
Transmit/Receive transducer
connector 2
Transmit/Receive
transducer connector 1
microSD memory card
slot
Battery door
Battery compartment
