Figure 6-22 One grid for 75 identical parts
Alternatively, the rows and columns of a grid may refer to a two-dimensional map of
measurement points on the surface of one part. In this case, a different grid is created
for each part (see the examples in Figure 6-23 on page 101).
Row
Column
Measurement location
ID
