Labels and Symbols
1
Labels and Symbols
Safety-related labels and symbols are attached to the instrument at the locations
shown in Figure i-1 on page 1 and Figure i-2 on page 2. If any or all of the labels or
symbols are missing or illegible, please contact Olympus.
To avoid the risk of electric shock, do not touch the inner conductor of the T/R 1 and
T/R 2 connectors. Up to 200 V can be present on the inner conductor. The warning
symbol between the Transmit/Receive (T/R) connector markings warns of this electric
shock risk.
Figure i-1 The symbols on the top of the 45MG
