DMTA-10022-01EN, Rev. C, January 2015
Chapter 1 20
Figure 1-1 The 45MG hardware components — Front, top, and side views
1.4 Connectors
Figure 1-2 on page 20 illustrates the possible connections between the 45MG and
external devices.
Figure 1-2 The 45MG connections
Protective rubber
boot
Stand
Strap rings (at the
four corners)
Color display
Keypad
I/O door protecting USB
connector
Transducer
connectors
Power key
USB connector
Transducer
microSD memory
card
