DMTA-10022-01EN, Rev. C, January 2015
Chapter 7
130
Figure 7-3 Displaying the minimum and/or maximum thickness (shown with the
Waveform option activated)
The fastest display update rate is automatically activated when entering the minimum
or maximum thickness mode. When leaving the mode, the display update rate is
restored to its previous state.
Active reading
Minimum thickness
Active reading
Maximum thickness
Recalled maximum during LOS
Maximum thickness
Active reading
Minimum and maximum
thicknesses
