Olympus 45MG - Table 18 Display EN15317 Specifications; Table 19 Transmitter EN15317 Specifications; Table 20 Receiver EN15317 Specifications; Table 21 Other EN15317 Specifications

DMTA-10022-01EN, Rev. C, January 2015
Appendix A 210
Table 18 Display EN15317 specifications
Parameter Value
Type Color graphical TFT, LCD, 320 × 240 pixels
Size [Height] × [Width], [Diagonal]
41.15 mm × 54.61 mm, 68.58 mm
(1.62 in. × 2.15 in., 2.70 in.)
Table 19 Transmitter EN15317 specifications
Parameter Value
Transmitter pulse Adjustable square wave pulser
Pulser voltage Pulse voltages: 60 V, 110 V, 150 V, and 200 V
Pulse rise time Damping in: 5 ns typical
Damping out: 3.5 ns typical (pulse-width dependent)
Pulse duration Adjustable to probe frequency
Table 20 Receiver EN15317 specifications
Parameter Value
Gain control Automatic or manual: 40 dB to 99 dB
Frequency range 0.5 MHz to 24 MHz typical (filter dependent)
Table 21 Other EN15317 specifications
Parameter Value
Data storage Internal and external microSD memory cards, maximum
capacity of 2 GB.
Each card:
475000 thickness readings or
20000 waveforms with thickness readings
Data output types 2.0 USB client
Removable microSD memory card
Calibration setting storage Default single and dual element transducer setups
35 custom setups (single element)
