DMTA-10022-01EN, Rev. C, January 2015
Software Options 89
6.7.1 Datalogger
The 45MG datalogger is a file-based system, in which one file is opened at a time. The
active file stores a measurement at a thickness-measurement location ID. Each time
you press [SAVE], the displayed value is saved to the active file at the current ID. The
ID is automatically incremented for the next measurement. When you press [FILE],
the name of the active file appears in the ID bar above the menu (see Figure 6-15 on
page 89).
Figure 6-15 The active file name appears in the ID bar
The file also contains header parameters that can be defined to better describe the
content of the file. In the file, you can organize the ID range, select the data format,
and select the saved data. Table 5 on page 89 summarizes the contents of a file, and
indicates where you can find more information.
Table 5 File contents summary
Contents Description See section
Header Extra parameters to describe the contents and
the context of the data
“Creating a
Data File” on
page 92
Name of the active file
