DMTA-10022-01EN, Rev. C, January 2015
Technical Specifications
209
Appendix A: Technical Specifications
Table 17 General EN15317 specifications
Parameter Val ue
Size Height × Width × Depth (without protective boot):
162.0 mm × 91.1 mm × 41.1 mm
(6.38 in. × 3.59 in. × 1.62 in.)
Weight 430.9 g (0.95 lb)
Power supply types Three AA-size batteries: Alkaline (nonrechargeable), NiMH
(externally rechargeable), or lithium (nonrechargeable)
Probe socket types Dual LEMO with center pin IP67
Battery operating time For continuous measurement at an update rate of 4 Hz with
the backlight set to 20 %:
Alkaline (nonrechargeable) 20–21 hours
NiMH (externally rechargeable) 22–23 hours
Lithium (nonrechargeable) 35–36 hours
Operating temperature −10 °C to 50 °C (14 °F to 122 °F)
Battery storage temperature −20 °C to 40 °C (−4 °F to 104 °F)
Battery indicator Five-step battery charge level indication
Pulse repetition frequency
(PRF)
1kHz burst
Measurement rates: 4 Hz, 8 Hz, 16 Hz, and Fast or Max (up to
20 Hz)
Alarm indicators Visual high-alarm and low-alarm indicators with audio tone
Thru coating Echo-to-echo and THRU-COAT measurements
Minimum and maximum
thickness
Single element: 0.1 mm to 635.0 mm (0.004 in. to 25.0 in.)
Dual element: 0.5 mm to 635.0 mm (0.020 in. to 25 in.)
Note: The exact thickness range depends on the transducer
type and measurement mode used.
