DMTA-10022-01EN, Rev. C, January 2015
Software Options
67
6. Software Options
The available software options can be used to increase the capability of the already
versatile 45MG (see Table 3 on page 67).
Table 3 45MG software options
Option
Part
number
Description
Echo-to-Echo &
THRU-COAT
45MG-EETC
(U8147021)
Enables the 45MG to make measurements in
Echo-to-Echo and THRU-COAT modes. These
features are used to measure the remaining
metal thickness when the material is
painted/coated.
Note: Manual Echo-to-Echo is only available
when the Waveform option is also purchased.
Datalogger
Capability
45MG-DL
(U8147020)
Adds a bidirectional alphanumeric file-based
datalogger. This option also includes a USB
communication cable and the GageView
interface program.
Waveform 45MG-WF
(U8147019)
Provides the added capability of viewing the
live A-scan of the ultrasonic signal.
