DMTA-10022-01EN, Rev. C, January 2015
Technical Specifications 213
DEFM1-2.25-M1036 M1036 Steel: 2.00 mm to 635.00 mm (0.080 in. to 25.000 in.)
DEFM3-20.0-M208 M208 Steel: 0.25 mm to 5.00 mm (0.008 in. to 0.200 in.)
DEFP2-20.0-M208 M208 Plastic: 0.12 mm to 5 mm (0.005 in. to 0.200 in.)
DEFM3-10.0-M202 M202 Steel: 0.25 mm to 12.00 mm (0.010 in. to 0.500 in.)
DEFM2-10.0-M202 M202 Steel: 0.75 mm to 12.00 mm (0.030 in. to 0.500 in.)
DEFP2-10.0-M202 M202 Plastic: 0.6 mm to 6 mm (0.025 in. to 0.25 in.)
DEFM3-15.0-V260 V260 Steel: 0.25 mm to 5.00 mm (0.010 in. to 0.200 in.)
DEFM2-15.0-V260 V260 Steel: 0.75 mm to 12.50 mm (0.030 in. to 0.500 in.)
DEFP2-15.0-V260 V260 Plastic: 0.25 mm to 3 mm (0.010 in. to 0.120 in.)
DEFM2-5.0-M201 M201 Steel: 1.50 mm to 25.40 mm (0.050 in. to 1.000 in.)
DEFP2-5.0-M201 M201 Plastic: 0.62 mm to 12.5 mm (0.025 in. to 0.500 in.)
DEFM2-5.0-M206 M206 Steel: 1.25 mm to 19.00 mm (0.050 in. to 0.750 in.)
DEFP2-5.0-M206 M206 Plastic: 1 mm to 12.5 mm (0.040 in. to 0.500 in.)
DEFM2-2.25-M207 M207 Steel: 2.00 mm to 19.00 mm (0.080 in. to 0.750 in.)
DEFP2-2.25-M207 M207 Plastic: 2 mm to 12.5 mm (0.080 in. to 0.500 in.)
DEFM1-0.5-M101 M101 Steel: 12.5 mm to 635 mm (0.500 in. to 25.00 in.)
DEFM1-1.0-M102 M102 Steel: 5.0 mm to 635 mm (0.200 in. to 25.00 in.)
DEFM1-1.0-M103 M103 Steel: 2.5 mm to 635 mm (0.100 in. to 25.00 in.)
DEFP1-0.5-M2008 M2008 Fiberglass: 5.0 mm to 75 mm (0.200 in. to 3.00 in.)
a. The maximum thickness measuring capability depends on the transducer type, material
conditions, and temperature.
Table 26 Setup parameter description
Name Description Units/Resolutions/Range
MEAS
OPTION
Echo detect mode Standard dual
Dual Echo-to-Echo
THRU-COAT
Mode 1
Mode 2
Mode 3
Table 25 Typical ranges and default setups for single element
transducers
a
(continued)
Setup name Transducer Typical measurement range
