CIBANO 500 PTM User Manual
200 OMICRON
Disconnection
Do not disconnect the circuit breaker but leave it connected for performing the next test. For
disconnecting the circuit breaker, see "Disconnection" on page 211.
Switching time Closing or opening time of the auxiliary contact depending on its type
Duration Duration the wiper contact remains closed
Diff. to main Time difference between the opening or closing of the auxiliary contact and
the corresponding main contact
Assessment Assessment of auxiliary contact characteristics
1. Only calculated for O and C sequences
Table 17-54: Main contact characteristics
1
1. Only available for O and C sequences
Data Description
Main contact Main contact this measurement row refers to
Bounce time
2
2. Not available for PIR contact system
Duration of the main contact bounce
Bounce count
2
Number of main contact bounces within the bounce time
PIR closing time Closing time for pre-insertion resistors
Assessment Measurement assessment
Table 17-55: Coil characteristics
Data Description
Peak current Peak current value through a trip or close coil
Average current Average current through the coil (see Average coil current/voltage
settings in Table 17-50: "Advanced settings of the Dynamic Contact
Resistance test" on page 196)
Average voltage Average voltage applied to the coil (see Average coil current/voltage
settings in Table 17-50: "Advanced settings of the Dynamic Contact
Resistance test" on page 196)
Resistance Calculated resistance of the coil
Assessment Assessment of coil characteristics
Table 17-53: Auxiliary contact characteristics
1
(continued)
Data Description
