OMICRON 23
Functional scheme
The following table describes the terminals of the functional scheme of CIBANO 500 with the EtherCAT
®
module.
Table 4-1: Terminals of CIBANO 500 with the EtherCAT
®
module
Terminal Description
Mains interface
L Mains phase
N Mains neutral
PE Equipotential ground
Communication interfaces
I1
4 × external EtherCAT
®
modules
I2 1 × Ethernet
I3 1 × serial
I4 2 × safety
External booster
E1 External booster phase
EN External booster neutral
PE Equipotential ground
I/O A
A1 Input/output A1
A2 Input/output A2
A3 Input/output A3
AN Input/output AN
I/O B
B1 Input/output B1
B2 Input/output B2
B3 Input/output B3
BN Input/output BN
B4 Input/output B4
Voltage input
V1 Voltage input 1
VN Voltage input N
