2. Optionally, enter the advanced settings in the Advanced settings area.
Test current per channel
Output current of each CB MC2 current channel
3
Sequence
Test sequence Test sequence to be performed
Trigger setting
4
Threshold Threshold value of the trigger signal
The measurement starts if the trigger signal rises above (rising edge) or falls
below (falling edge) the threshold.
Edge type Rising or falling edge
1. Only available in the guided test workflow and if CIBANO 500 is selected as source
2. Data taken from the nameplate
3. We recommend using a test current of 100 A per CB MC2 channel for the most accurate results.
4. Only available if VIN, or one output in group A or group B is set to Trigger IN.
Table 17-71: Advanced settings of the Timing (CSM) test
Setting Description
Other
Close breaker before
test
1
1. The Close breaker before test check box is only active if the test sequence begins with the open command and no output is
set to Trigger IN.
Select the Close breaker before test check box to automatically close the
circuit breaker 1 second before starting a measurement.
Sample rate
Measurement sample rate
2
2. We recommend 40 kHz to get the most accurate test results.
Contact bounce filter
Auxiliary contact Threshold value of the time interval between two consecutive bounces of
the auxiliary contact. For time intervals equal or below the threshold, the
contact is considered as closed.
Setting the value to 0.0 ms deactivates the contact bounce filter.
Average coil current/voltage
Begin Start of the average coil current/voltage evaluation in percent of the time
period during which the current flows through the coil
End End of the average coil current/voltage evaluation in percent of the time
period during which the current flows through the coil
Sequence
See Table 17-72: "Timing (CSM) test sequences" on page 233.
Table 17-70: Settings of the Timing (CSM) test (continued)
