CIBANO 500 PTM User Manual
238 OMICRON
2. Optionally, enter the advanced settings in the Advanced settings area.
Coil supply voltage start Start voltage of the automated test sequence to determine the minimum
pickup voltage
Coil supply voltage end End voltage of the automated test sequence to determine the minimum
pickup voltage
Coil supply voltage step Stepwise voltage increase of the automated test sequence
Motor supply
Supply source Click CIBANO 500 to supply the motor with CIBANO 500.
Click External source to supply the motor externally.
Supply settings
1,2,3
Select the preconfigured motor supply setting from the asset data or select
Custom to enter custom settings.
Motor supply voltage Rated voltage of the motor supply
Click AC or DC for AC or DC motor supply voltage respectively.
Test frequency Motor supply frequency (AC only)
Max. supply duration Maximum duration of supplying the motor if not stopped automatically
1. Only available in the guided test workflow
2. Data taken from the nameplate
3. Only available if CIBANO 500 is selected as source
Table 17-78: Advanced settings of the Minimum Pickup test
Setting Description
Supply during coil supply
Enable Select the Enable check box to supply voltage on the B3 socket during test
execution.
1
1. The B3 socket must be configured as Supply and the coil supply voltage must be specified.
Supply voltage Voltage supplied on the B3 socket (same as the coil supply voltage)
Supply before test Time interval within which the voltage is supplied before the test starts
Test sequence
Command impulse
duration
Duration of the command pulse of the automated test sequence
Pause between
impulses
Time interval between impulses of the automated test sequence
Table 17-77: Settings of the Minimum Pickup test (continued)
Setting Description
