Performance Monitor SECTION 16 Application Analysis / Performance Monitor
241
Total Active Points
Total Active Elements The number of active memory addresses on a
PLC - the Active points could be in arrays of many
elements so the Elements is a better guide to how
much memory on the PLC you are addressing.
This number should not be a 'surprise' - if this
number looks large you need to consider if you are
using and updating too many points at once and
affecting performance.
TX Bytes (CX-Server) RX
Bytes (CX-Server)
The bytes transmitted or received to the PLC from
CX-Server.
TX Bytes (CX-Supervisor) The number of bytes transmitted from CX-
Supervisor to CX-Server
TX Bytes/Sec (CX-
Supervisor)
The current number of bytes per second being
transmitted from CX-Supervisor to CX-Server, this
should be kept well below the bandwidth capacity
of the network being used. Also take into account
other bandwidth use such as received data and
other unrelated network traffic.
